800mm EV charger protection guard, 48mm steel tube, galvanised

Robust steel barrier guard designed to protect EV charging points from vehicle collision damage.

This charging point protection guard is manufactured from 48mm diameter mild steel tube with hot dip galvanised finish for durability and low maintenance. Choose between surface-mounted (baseplate) or root-fixed (in-ground) installation to suit your site. Retro-reflective rings enhance visibility in low-light conditions.

Key Features

• 48mm outer diameter steel tube with 2.5mm wall thickness
• Hot dip galvanised or galvanised with powder coat black finish options
• Retro-reflective rings for improved visibility
• Surface-mounted baseplate or underground root-fixed installation
• Economical protection solution for charging infrastructure

Specifications

• Material: mild steel, hot dip galvanised
• Width: 800mm
• Surface-mounted height: 750mm
• Root-fixed overall length: 1050mm
• Tube diameter: 48mm OD, 2.5mm wall
• Approximate weight: 8kg
• Finish options: galvanised or galvanised with powder coat black

Applications

• Public EV charging point protection
• Workplace charging station safeguarding
• Retail and commercial charging infrastructure
• Vehicle impact damage prevention
• Long-term charging point preservation
