Open-Fronted Cycle Shelter | Galvanised Steel | 2–5m Length

Open-sided galvanised steel cycle shelter with curved roof, designed for secure weather protection and on-site assembly.

This free-standing shelter is constructed from high-grade galvanised mild steel with a 1mm galvanised sheet curved roof. Available in four lengths (2m, 3m, 4m, 5m) to accommodate 4–12 cycles, it combines practical durability with clean aesthetic lines suitable for commercial and institutional settings.

Key Features

• Galvanised mild steel frame and 1mm curved roof panels for corrosion resistance
• Open-fronted design for easy cycle access and visibility
• Four capacity options: 2m (4 cycles), 3m (8 cycles), 4m (10 cycles), 5m (12 cycles)
• Angled roof profile sheds water effectively
• Bolt-down foundation plates (1224mm × 300mm × 8mm, 8 bolts per shelter)
• On-site assembly and installation

Specifications

• Front height: 2381mm
• Rear height: 1569mm
• Width: 1913mm
• Length options: 2m, 3m, 4m, 5m
• Construction: Galvanised mild steel
• Roof: 1mm galvanised sheet curved profile
• Foundation: Galvanised steel flange plates with bolt-down fixings
• Note: Cycle racks not included

Applications

• Workplace and office cycle parking
• Educational campuses and school bike storage
• Transport interchanges and railway stations
• Residential developments and apartment complexes
• Public facilities and leisure centres
