Premium High-Pressure Butyl Delivery Hose for Brewery and Distillery Applications - 16 Bar Performance with Chemical Resistance

Product Overview

This Premium High-Pressure Butyl Delivery Hose is specifically designed for brewery and distillery applications, capable of withstanding working pressures greater than 16 bar. Its thicker wall provides excellent resistance to kinking, making it ideal for transferring various beverages.

Applications

• Beer & Lager
• Cider & Perry
• Stouts & Ales
• Fruit Juice
• Soda & Soft Drinks
• Wine
• Spirits (up to 92% vol.)
• Whisky
• Potable Water

Material and Construction

The hose features a Butyl rubber liner, recognized as the best rubber compound for low permeation and outstanding chemical resistance. This durability allows the hose to endure regular cleaning processes, including CIP (Clean-in-Place) cleaning, ensuring a longer service life compared to other rubber materials. Additionally, Butyl rubber meets non-smell, non-toxic, and non-taint requirements, making it suitable for a wide range of food and drink products.

Certifications and Compliance

This delivery hose is compliant with various international standards:

• FDA 21 CFR 177.260 - for rubber products intended for repeated use in food processing.
• BFR XXI – Cat 2 – German Federal Institute for Risk Assessment.
• DM 21/03/1973 – Italy – Hygienic rules for contact with foodstuffs.
• Regulation 1935/2004/CE – EU standards for food contact materials.
• Notice No 370,1959 – Japan – Specifications for food use.
• 3-A RPSCQC for (62-02) Hose Assemblies – standards for dairy and food production.
• Arrêté du 5 août 2020 – France – Rubber materials for food contact.
• Temperature suitability: -40°C to +120°C.
• Phthalates Free and compliant with 1907/2006/CE (REACH).

Technical Specifications

The Premium Butyl Delivery Hose is engineered to meet demanding requirements in the brewery and distillery sectors. Here are its technical specifications:

• Pressure Rating: 16 bar
• Construction Material: Butyl rubber
• Temperature Range: -40°C to +120°C
• Phthalates: Free
• Compatibility: Suitable for most food and drink products

Maintenance and Cleaning

This hose can be effectively cleaned and sterilized through various processes, including CIP. For thorough guidance on cleaning methods, please refer to separate documentation.

FAQs

1. What beverages can be transferred using this hose?

The hose is suitable for transferring beer, cider, stouts, fruit juice, soda, wine, spirits, whisky, and potable water.

2. Is this hose safe for food and drink applications?

Yes, the hose is made from FDA-compliant materials and is designed for safe contact with food and beverages.

3. What is the temperature range for this delivery hose?

The hose can operate within a temperature range of -40°C to +120°C.
