Premium 6 Bar Food and Drink Hose Assembly - Flexible NR Rubber with FDA Approval for Beverage Transfer

Premium 6 Bar Food and Drink Hose Assembly - Flexible NR Rubber with FDA Approval for Beverage Transfer

£91.06 GBP
£91.06 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.
Bore/Hose Size

Overview

The Premium food and drink hose assembly is highly respected in the Food and Drink sector. It is an extremely flexible hose that provides exceptional ease of handling to the food, brewery, dairy, and beverage industries. This hose can transfer liquids such as fruit juice, wine, cider, beer, vinegar, alcohol up to 96%, and drinking water. Note: Not suitable for fatty foodstuffs and oils.

Construction

The hose is constructed with an FDA-approved smooth seamless white NR liner, making it resistant to detergents used in hose sterilization. The outer cover is made of non-marking NR blue rubber, offering excellent resistance to abrasion, ozone, and chemicals used in cleaning processes.

Length and Couplings

This hose can be supplied in continuous lengths up to 40m but is mostly provided in bespoke assemblies. We offer assemblies with the following coupling types in 316 stainless steel:

  • BSP
  • RJT
  • Triclover/Tricclamp style
  • IDF
  • DIN
  • SMS

All assemblies are 100% pressure tested and supplied with individual identification and test certificates.

Applications

  • Suitable for milk tankers, processing and filling plants.
  • Ideal for the transfer of beer, wine, cider, fruit juice, vinegar, and alcohol > 96%.
  • Extremely flexible, can achieve a very small bend radius without kinking.
  • Smooth seamless white tube that does not propagate bacterial growth and meets European and USA regulations.
  • Unaffected by changes in temperature, unlike PVC products.
  • Resistant to cleaning with detergents or steam to a maximum temperature of 110°C.
  • Non-marking abrasion-resistant cover.
  • Contains no Phthalate.

Technical Specifications

Specification Measurement
Inner Tube Food grade NR, white, smooth
Reinforcement Synthetic textile with embedded steel helix
Cover Weather and abrasion resistant NR, blue
Temperature Range -30°C to +80°C
Sizes From minimum ID of 25.0mm/ OD of 36.0mm to maximum ID of 150.0mm/OD of 171.5mm
Working Pressure 6 bar across all bore sizes
Bursting Pressure 18 bar across all bore sizes
Standard Approval EU regulation no. 1935/2004 and 2023/2006 FDA regulation no. 21 CFR 177.2600

FAQ

  • What types of liquids can be transferred using this hose?
    This hose is suitable for transferring fruit juice, wine, beer, cider, vinegar, and alcohol up to 96%.
  • Is this hose resistant to cleaning agents?
    Yes, it is resistant to cleaning with detergents or steam up to a maximum temperature of 110°C.
  • Can the hose be customized in length?
    Yes, the hose can be supplied in continuous lengths up to 40m.
