Empteezy
Thermostatic Safety Valve - TSV
Thermostatic Safety Valve - TSV
Regular price
£966.00 GBP
Regular price
Sale price
£966.00 GBP
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
A hot and cold water mixing valve providing tepid water from 20°C to 43°C (adjustable) at a minimum rate of 122lpm at 2 bar. Should the hot water supply fail the systems internal by-pass continues to deliver cold water at a minimum of 105lpm at 2 bar. If the cold water supply fails the system shuts the hot water supply off to prevent scalding.
| Connection: | 1½” Male with optional kit including two 1” male adapters with check valves on the inlets. |
| Water inlet pressure (hot & cold): | Recommended 2 bar with a maximum of 8 bar - please notify us prior to ordering if your water pressure is below 1.5 bar. |
| Hot water supply temperature: | Optimum 50-70°C (Maximum 100°C) |
| Cold water supply temperature: | 5-10°C (Maximum 23°C) |
| Fully closed temperature: | 35°C |
